Procet Industrial Gigabit 10G Fiber PoE Injector, Waterproof Outdoor Use. 802.3af/at/PoE++ Standard PoE. Input 100-240Vac 2.0A, Output 55Vdc 1750mA. 6kv Surge Protection, Working Temperature from -40°C-65°C.
Enclosed in an IP67 reflective Aluminum case with sealing that gasket passes tension, bearing, corrosion, and aging test for IP67 applications. Pass salt spray resistance test Including 1 AC input port, 1 SFP+ port at 10GBASE-X, and 1 PoE output ports with 6KV (10/700us) surge protection.
Complies with PoE++ and any IEEE802.3af/at compliant devices, such as Wi-fi 6, wireless APs, Microwave radio, IoT application, door locks, IP Cameras, information kiosks, and other PoE devices. Operates under -40℃ to +65℃. Easily to install with installation kit (sold separately), no need to open the equipment. Specially designed for exterior, complex backhaul and networking applications, special scenarios, like highway side, exurb, etc.
Specifications
| Parameter | Description |
| Key Features | 1000Base-FX to 1000Base-TX SFP slot for Multimode or Single-mode SFP transceiver Lightning protection 6KV(10/700us) Support IEE802.3af/at standard PD Working Temperature: -40℃ to 65℃ Outdoor IP67, metal casing |
| Part Number | PT-PSE108GBRS-OT-10 |
| Ports condition | SFP Port*1, PoE Output Port*1, AC Input Port *1 |
| Regulatory Compliance | FCC CFR47 Part 15, EN55024, EN55032 |
| Pass-Through Data Rates | 10/100/1000Mbps 2.5G/5G/10G |
| Output | Power Pins: 3/6(+), 1/2(-), 4/5(+), 7/8(-) 55Vdc 1750mA |
| Input | 100-240Vac 2.0A 50/60Hz |
| Working Environment | Operating Temperature: -40℃ to 65℃ Operating Humidity: 20% to 80%, non-condensation Storage Temperature: -40℃ to 85℃ Storage Humidity: 10% to 95%, non-condensation Operating Altitude: up to 5000meters |
| PoE Surge Protection | Protected line: 1,2,3,4,5,6,7,8 Common mode surge protection(10/700us): 6KV Differential mode surge protection (10/700us): 1.5KV |
| Mechanical Characteristics | Case: Aluminum Color: White Mounting: Wall-mounted/Pole-mounted IP Rated: IP67 Size: 176mm X 269mm X 65mm Weight: 1.8kg |
