PoE (Power over Ethernet) network power supply products.
FAQ
What devices are compatible with the PT-PSE10GF series PoE injector?
The PT-PSE10GF series complies with IEEE 802.3af and supports PoE-enabled devices such as IP cameras, wireless access points, and IP phones, with a maximum output of 15.4W. Its built-in PoE detection helps ensure power is supplied only to compatible devices. It also supports Gigabit Ethernet and transmits power and data over a single Cat5e/Cat6 cable, up to 100 meters.
Can the PT-PSE118GBR-OT-10 deliver 60W throughout its entire -40°C to 65°C operating range?
No. It provides up to 60W at 50°C, 45W at 55°C, and 30W at 65°C. It supports full-load startup at -40°C.
Can the injector run at full load at 65℃?
Yes. It supports full-load cold start at -40℃ and continuous full-load operation at an ambient temperature of 65℃.
It really can be used outdoors in rain, snow, or direct sunlight?
Yes, absolutely. It can be installed outdoors without an additional waterproof enclosure.
Can I use a 12Vdc power source and still get a 55Vdc PoE output?
Yes. The injector accepts 12.0Vdc and boosts it to 55Vdc.
Can I use this injector in my yard to power a camera?
Yes, it just needs proper protection. Install the injector in a suitable waterproof enclosure and provide proper grounding.
Can the PT-PSE105GB-D power an IEEE 802.3bt device?
Yes. More specifically, it supports IEEE 802.3bt devices below Class 7.
My Wi-Fi 7 AP has a 2.5Gbps data rate. Can this injector provide a stable connection?
Sure. It support data rates up to 10Gbps and is fully compatible with 1/2.5/5Gbps connections.
Does this device support redundant AC and DC power inputs? I want to connect it to both AC power and a battery so it can automatically switch to battery power if the AC power fails.
No. You can use either the AC input or the DC input, but not both at the same time.
Can I use the fiber connection as the primary data link and the Ethernet connection as a backup to prevent an interruption if the fiber link fails?
Yes, you can use it this way. However, do not connect both the fiber and Ethernet links to the same upstream device at the same time.
I see that this injector can be managed by web browser. Does that mean I can remotely turn off a wireless radio located in a house more than 20 km away?
Yes. You can remotely power off the PD, view the port and device status, or restart the PoE port if the data link goes down.
Since the injector supports a wide operating temperature range, can I use it outdoors?
Yes, as long as it is installed in a suitable location, such as inside a waterproof enclosure.
Can this injector power a device that typically consumes 65W but draws up to 98W at startup?
Not recommended. The PT-PSE109GBROA-VI caps out at 95W, but your device needs up to 98W at startup. With power loss over the cable, the device may not start properly.
I saw that this injector has 6kV surge protection Can it be installed under the eaves?
Not directly. We recommend an outdoor injector, as mounting an indoor model under the eaves cannot fully protect it from moisture and dust.
Do you offer a compatible power supply for this injector?
No. You need to buy a AC-DC power supply from Amazon.
Does the injector have the required certification for India? I will use it there.
Yes, the PT-PSE106GW is BIS certified.
Can the PT-PSE104GB-VI power high-wattage devices?
Yes, it provides up to 60W, supporting APs, cameras, and other PoE devices.
I purchased an IP camera that requires 802.3at compliance. Can I use this injector?
Yes, this is a 802.3bt standard PoE injector, and it's compatible with the 802.3at.
Will the injector provide poe if there is no connection to a router in the lan side? I just need power to my wireless camera
The router is not required, but the connection to the camera has to be POE. You could make a cable to pull the power from the POE connector to supply the power to the camera, but this seems over complicated. Why not just run a power line for the camera ?
I have a wireless station compliant with bt standard Class 7 . Can this injector power it?
Sorry, this unit is not suitable for your device.
Does the 88% efficiency cover the full 100-240V AC input range?
Exactly.
Will the PT-PSE104GO-30 send power to a non-PoE device?
No. It detects whether the connected device is IEEE 802.3af/at compliant before supplying power.
Will the injector slow down my network?
Not if the injector supports the same data rate as your switch and device. The connection will run at the lowest speed supported by the switch, injector, or connected device.
Can I connect any 48VDC PoE device directly to the PT-PSE100G?
Only be used with 48V PoE devices through pins 4/5 (+) and 7/8 (-).
Will this injector work with all my IP camera or wireless access point?
A: Not necessarily. Check the PoE standard, output voltage, and power rating before connecting it. The injector needs to match the power requirements of your device.
Will the EN30GT-10 send power to a non-PoE device?
No. The detection chip identifies the powered device before applying power. If the connected device is not compliant with the PoE standard, the injector will not supply power.
What types of devices can the EN30GT-10 power?
It supplies up to 30W to IEEE 802.3af/at powered devices.
Will the EN30GT send power to a non-PoE device?
No. The detection chip identifies the powered device before applying power. If the connected device is not compliant with the PoE standard, the injector will not supply power.
What types of devices can the EN30GT power?
It supplies up to 30W to IEEE 802.3af/at powered devices.
I saw that this injector has 6kV surge protection. Can it be installed under the eaves?
Not directly. For installation under the eaves, place the injector inside a waterproof enclosure and use additional outdoor lightning protection for the connected PD.
Does the PT-PSE100GF support Gigabit Ethernet?
Yes. It supports 10/100/1000Mbps Ethernet and can transmit power and data up to 100 meters over Cat5e/Cat6 cable.
Can the injector supply power without router or switch connected to the LAN port?
The PoE output can power a detected IEEE 802.3af-compliant device. A LAN connection is only required when network data transmission is needed.
What types of devices can the PT-PSE100GF power?
It is designed for IEEE 802.3af powered devices up to 15.4W, such as wireless access points, IP cameras and IP phones.
PT-PSE10GF-25 actually support true 2.5Gigabit?
Sure.
Can the injector supply power without a router or switch connected to the LAN port?
Yes. The AC-powered injector can supply power to a detected IEEE 802.3af-compliant device through the PoE port. A LAN connection is only required when network data transmission is needed.
Does the EN15GF-B support Gigabit Ethernet?
Yes. It supports 10/100/1000Mbps Ethernet and can transmit power and data up to 100 meters over Cat5e/Cat6 cable.
What types of devices can the EN15GF-B power?
It is designed for IEEE 802.3af powered devices up to 15.4W, including IP cameras, telecom equipment, security systems, IoT devices, displays, POS terminals and information kiosks.
