PT-PSE106SAR48-24 Indoor 24Vdc Midspan Injector

PT-PSE106SAR48-24  is an indoor-rated PoE midspan Injector specially designed for complex backhaul and networking applications. Enclosed in an IP40 fire retardant plastic case.

Passive PoE directly power PDs without detecting, the single PoE output port delivers 24Vdc, 1.25A up to 30W power with 6KV surge protection for remote PDs over 2 Pair at 10/100/1000Mbps data rates.  It works with DC input voltage of 44-57Vdc. It is capable of powering 30 watts non IEEE802.3af/at PoE Powered Devices (PD’s) and supports 802.3af/at compliant devices, such as IP Cameras, wireless APs, Microwave radio, ONU IP Phones and IoT application.

For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables.

  • Specifications
  • Support & Dowload
  • Gallery
  • Test Results
  • Standing Stock


Key FeaturesLighting Protection
Buck PoE
Gigabit data rates
Reverse polarity protection for DC input
Electrical Isolated design between Input and Output inside to avoid high current input damage
Part NumberPT-PSE106SAR48-24
Ports conditionLAN Port*1, DC Input Port*1, PoE Output Port*1
Regulatory ComplianceRoHS Compliance
WEEE Compliance
Pass Through Data Rates10/100/1000 Mbps
OutputPin Assignment and Polarity:
4/5 (+), 7/8 (–)
Output Power Voltage: 24Vdc
User Port Power: 30W Guaranteen
InputDC Input Voltage: 44 to 57 Vdc
DC Input Current: 1.0A
Working EnvironmentOperating Temperature: 0 to 40
Operating Humidity: 20% to 80%, non-condensation
Storage Temperature: -20
to 70
Storage Humidity: 10% to 90%, non-condensation
Operating Altitude: up to 2000meters
PoE Surge ProtectionProtected line: 1,2,3,4,5,6,7,8
Common mode surge protection(10/700us): 6KV
Differential mode surge protection (10/700us): 1.5KV
Mechanical CharacteristicsCase: Plastic
Color: Black
Mounting: Wall-mounted
IP Rated: IP40
Connectors: Shielded RJ-45
Size: 120mm X 125mm X 44mm
Weight: 280g
LED IndicatorPower Indicator: Green
PoE Load Indicator: Green
Warranty2 year


Standing Stock

Product Order Info.(Model)PT-PSE106SAR48-24
Stock Quantity200PCS
Warehouse Location Dongguan China
Sample Delivery TimeWithin 24H
Bulk Stock Delivery TimeWithin 48H
Shipping WayDHL,UPS,FedEx,   TNT,
Customer Nominated Forwarder
Packing SizeQty: 20pcs/carton
G.W.: 16Kgs
Volume: 0.06 m³
Packing: Export Carton
Pallet size: 110 x 110cm
