PT-PR01G-10 10G PoE Surge Protector

PT-PR01G-10 is a single-port Ethernet surge protector. Enclosed in an Aluminum Alloy shell, with a silver color exterior, complemented by an anodized aluminum surface. Enhanced RJ45 socket exhibits minimal signal attenuation. High-quality Gas discharge tube(GDT). Withstand extreme environmental conditions within a temperature range of -40 to 85 degrees Celsius. Max Discharge Current: 10KA (8/20us, 1.25KA per line). Supports power of 120W, 60Vdc(max) Ethernet equipment.


PT-PR01G-10 can not only work with IEEE802.3af/at/bt/PoE++ standard devices, but also supports non-standard Ethernet equipment, that well protects your devices against surge damage. And it can support 10/100/1000Mbps, 2.5/5/10Gbps data rate.The common mode surge voltage exceeds 10KV(10/700us) and the differential mode surge voltage is 1.5KV(10/700us).


  • Specifications
  • Support & Dowload
  • Gallery
  • Test Results
  • Standing Stock

Specifications

ParameterDescription
Key FeaturesStriking Appearance and Compact Design
Superior RJ45 Socket Performance,shows minimal signal attenuation
10KV surge protection and 10KA Discharge Current,Robust Surge Protection Capability
Working Temperature -40°C to 65℃
Not only work with IEEE802.3af/at/bt/PoE++ standard devices, but also supports non-standard Ethernet equipment
Withstand extreme environmental temperature from -40 to 85 degrees
Bidirectional Functionality,provides flexibility for network configuration
Provide lightning protection for wireless and cameras network equipment
Supports power of 120W, 60Vdc(max) Ethernet equipment
Part NumberPT-PR01G-10
StandardIEEE802.3i 10Base-T Ethernet
IEEE802.3u 100Base-Tx Fast Ethernet
IEEE802.3ab 1000Base-T Gigabit Ethernet
CE
IEEE802.3 af / at / bt / PoE++
RoHS Compliance
WEEE Compliance
Support 120W IEEE802.3bt and PoE++ standards
Support PoE wire with IEEE802.3af/at standards
Input & OutputOperating Voltage:60Vdc Max
Max Discharge Current:10KA(8/20us,1.25KA per line)
Maximum Operating Current:1A for 2 pairs, 2A for 4 pairs
Maximum Operating Power:120W
Data Speed: 10/100/1000Mbp & 2.5/5/10GbE
Operating EnvironmentOperating Temperature: -40℃ to 85℃
Operating Humidity: 20% to 80%, non-condensation
Operating Altitude:Up to 5000meters
Storage Humidity: 10%-90%,non-condensation
Storage Temperature: -40℃ to 85℃
PoE Surge ProtectionProtected line:1,2,3,4,5,6,7,8
Common Mode Protection Level(10/700us): 10KV
Differential Mode Protection Level(10/700us): 1.5KV
Insertion Loss @10MHz/100MHz:-1db
Return Loss @10MHz/100MHz: -20db
Response Time:5ns
Network ProtocolIEEE802.3i/IEEE802.3u/IEEE802.3ab
Safety ApprovalsCE
Mechanical CharacteristicsCase:Aluminum alloy
Color:Silver Zinc alloy case
Mounting: Wall mounted
Size:103mm X 28mm X 30mm
Weight:71.5g
IP Rated:IP40
EMIFCC CFR47 Part 15, EN55032, EN55035
